Mc4 Panel Mount Connector for Home Use
- Product Size: For 2.5mm,4mm,6mm cable
- Product Material: Tinned Copper PPO
MC4 Solar Connector is specialized used in Solar PV system between the solar panel and Inverter or controller box.They’re UV resistance and can be working outdoor for 25years.
Slocable mc4 panel mount connector for Home Use
Description of Panel MC4 Connector
· Compatible MC4
· Standard thickness 0.4 terminals
· Simple on-site processing
· Mating safety provided by keyed housings
· Multiple plugging and unplugging cycles
· Accommodates PV cables with different insulation diameters
· High current carrying capacity
Technical Data of Panel MC4 Connector
| Rated Current: | 50A |
| Rated Voltage: | 1000V/1500V DC |
| Certificate: | TUV , CE , ISO |
| Insulation Material: | PPO |
| Contact Material: | Copper, Tin plated |
| Waterproof Protection: | IP68 |
| Contact Resistance: | <0.5mΩ |
| Ambient Temperature: | -40℃~+85℃ |
| Flame Class : | UL94-V0 |
| Suitable Cable : | 2.5-6mm2 (14-10AWG) |
Pictures of Panel MC4 Connector
Comparison of MC4 Connector
Shopper satisfaction is our primary focus. We uphold a consistent level of professionalism, quality, credibility and repair for Mc4 Panel Mount Connector for Home Use, Sincerely look ahead to serving you within the vicinity of the foreseeable future. You happen to be sincerely welcome to go to our firm to talk small business face to face with each other and create long-term co-operation with us!
Shopper satisfaction is our primary focus. We uphold a consistent level of professionalism, quality, credibility and repair for 10kw Solar Kit Price, China Solar System for Home off Grid, With well-educated, innovative and energetic staff, we’re responsible for all elements of research, design, manufacture, sale and distribution. By studying and developing new techniques, we’re not only following but also leading the fashion industry. We listen attentively to the feedback from our customers and offer instant replies. You will instantly feel our expert and attentive service.
If any inquiry, please feel free to contact us. Many thanks!
-
